Stainless Steel Swivel Hoist Ring
Stainless Steel Swivel Hoist Ring Stainless-Steel-Swivel-Hoist-Ring-draw

Stainless Steel Swivel Hoist Ring

ADB Stainless Steel swivel hoist rings are designed for lifting. They rotate and pivot to absorb any pitch, roll or sway of unbalanced loads. Will not yield to heavy side loads. Help prevent the lifting hook from disengaging.

Category : Hoist Rings

CALL216-292-5585 OR EMAIL FOR THE MOST CURRENT PRICING

  • Description
  • Technical Specification

ADB Safety Engineered Stainless Steel Swivel Hoist Rings

  • Material: 300 Series Stainless Steel
  • Design Factor: 5:1, Hoist Rings retain the same rated load from 0 to 90 degrees from the bolt axis, Standard tolerance ± .030 inch unless otherwise specified
  • Range of Movement: Swivel 360°, Pivot 180° Under Load
  • Specifications: NDT: 100% Liquid Penetrant Tested Per MIL-STD-5002, ASTME 1417, Purification Process: Clean & Passivate Per ASTM A 967, QQ-P-35 TYPE II
  • Typical Applications: Use Stainless for Corrosive, Cryogenic or Elevated Temperature Environments

STAINLESS STEEL SAFETY ENGINEERED HOIST RINGS

Part No. Rated Load (lbs) A B C D E +/-.12 F +/-.060 G H +/-.060 J K L M TL (lbs-ft) Weight (lbs)
29050 275 .43 1.61 .71 3/8 .54 2.67 1/4-20 1.84 1.00 .75 .17 1.33 2.5 5 oz
29051 400 .43 1.61 .71 3/8 .29 2.67 5/16-18 1.84 1.00 .75 .17 1.27 3.5 5 oz
29052 400 .43 1.61 .71 3/8 .54 2.67 5/16-18 1.84 1.00 .75 .17 1.27 3.5 5 oz
29053 500 .43 1.61 .71 3/8 .54 2.67 3/8-16 1.84 1.00 .75 .17 1.21 6 5 oz
29301 1250 .70 2.40 .93 1/2 1.07 3.77 1/2-13 2.58 1.49 1.25 .20 1.84 14 1 lb
29004 1250 .88 3.25 1.22 3/4 .78 4.78 1/2-13 3.52 1.99 1.50 .16 2.31 14 2 lb. 5 oz
29322 1250 .88 3.25 1.22 3/4 .78 6.72 1/2-13 3.52 1.99 1.50 .16 4.25 14 2 lb. 12 oz
29005 1250 .88 3.25 1.22 3/4 1.03 4.78 1/2-13 3.52 1.99 1.50 .16 2.31 14 2 lb. 5 oz
29323 1250 .88 3.25 1.22 3/4 1.03 6.72 1/2-13 3.52 1.99 1.50 .16 4.25 14 2 lb
29006 1250 .88 3.25 1.22 3/4 1.28 4.78 1/2-13 3.52 1.99 1.50 .16 2.31 14 2 lb. 5 oz
29324 1250 .88 3.25 1.22 3/4 1.28 6.72 1/2-13 3.52 1.99 1.50 .16 4.25 14 2 lb. 12 oz
29001 2000 .88 3.25 1.22 3/4 .78 4.78 5/8-11 3.52 1.99 1.50 .16 2.18 30 2 lb. 7 oz
29002 2000 .88 3.25 1.22 3/4 1.03 4.78 5/8-11 3.52 1.99 1.50 .16 2.18 30 2 lb. 7 oz
29320 2000 .88 3.25 1.22 3/4 1.03 6.72 5/8-11 3.52 1.99 1.50 .16 4.12 30 2 lb. 14 oz
29003 2000 .88 3.25 1.22 3/4 1.28 4.78 5/8-11 3.52 1.99 1.50 .16 2.18 30 2 lb. 7 oz
29321 2000 .88 3.25 1.22 3/4 1.28 6.72 5/8-11 3.52 1.99 1.50 .16 4.12 30 2 lb 14 oz
29007 2500 .88 3.25 1.22 3/4 1.03 4.78 3/4-10 3.52 1.99 1.50 .16 2.06 50 2 lb 9 oz
29325 2500 .88 3.25 1.22 3/4 1.03 6.72 3/4-10 3.52 1.99 1.50 .16 4.00 50 3 lb
29009 2500 .88 3.25 1.22 3/4 1.53 4.78 3/4-10 3.52 1.99 1.50 .16 2.06 50 2 lb. 9 oz
29327 2500 .88 3.25 1.22 3/4 1.53 6.72 3/4-10 3.52 1.99 1.50 .16 4.00 50 3 lb
29102 3500 1.40 4.80 1.71 1″ 1.04 6.52 3/4-10 5.14 3.00 2.37 .24 3.06 50 6 lb. 10 oz
29329 3500 1.40 4.80 1.71 1″ 1.04 8.11 3/4-10 5.14 3.00 2.37 .24 4.65 50 7 lb. 4 oz
29103 3500 1.40 4.80 1.71 1″ 1.54 6.52 3/4-10 5.14 3.00 2.37 .24 3.06 50 6 lb. 10 oz
29330 3500 1.40 4.80 1.71 1″ 1.54 8.11 3/4-10 5.14 3.00 2.37 .24 4.65 50 6 lb. 10 oz
29101 4000 1.40 4.80 1.71 1″ 1.04 6.52 7/8-9 5.14 3.00 2.37 .24 2.93 80 6 lb. 12 oz
29328 4000 1.40 4.80 1.71 1″ 1.04 8.11 7/8-9 5.14 3.00 2.37 .24 4.52 80 6 lb. 12 oz
29105 5000 1.40 4.80 1.71 1″ 1.29 6.52 1″-8 5.14 3.00 2.37 .24 2.81 115 7 lb
29331 5000 1.40 4.80 1.71 1″ 1.29 8.11 1″-8 5.14 3.00 2.37 .24 4.40 115 7 lb
29106 5000 1.40 4.80 1.71 1″ 1.54 6.52 1″-8 5.14 3.00 2.37 .24 2.81 115 7 lb
29332 5000 1.40 4.80 1.71 1″ 1.54 8.11 1″-8 5.14 3.00 2.37 .24 4.40 115 7 lb
29107 5000 1.40 4.80 1.71 1″ 2.29 6.52 1″-8 5.14 3.00 2.37 .24 2.81 115 7 lb
29333 5000 1.40 4.80 1.71 1″ 2.29 8.11 1″-8 5.14 3.00 2.37 .24 4.40 115 7 lb
29401 7500 1.75 6.00 2.11 1-1/4 1.89 8.73 1-1/4″-7 6.50 3.76 3.20 .35 4.12 235 14 lb
29202 12000 2.25 8.00 2.81 1-3/4 2.70 12.47 1-1/2″-6 8.55 4.87 4.20 .47 6.41 400 33 lb. 12 oz
†29200 15000 2.25 8.00 2.81 1-3/4 2.96 12.47 2″-4 1/2 8.55 4.87 4.20 .47 5.41 400 36 lb
†29501 25000 3.00 10.50 4.09 2-1/4 4.00 16.87 2-1/2″-8 11.67 6.52 5.75 1.12 8.03 1050 87 lb. 8 oz
†29503 25000 3.00 10.50 4.09 2-1/4 4.00 16.87 2-1/2″-4 11.67 6.52 5.75 1.12 8.03 1050 87 lb. 8 oz
†29600 37500 3.75 13.00 5.27 2-3/4 5.20 19.50 3″-4 14.15 8.10 7.25 1.00 8.48 2150 166 lb
†29701 50000 4.00 14.50 6.06 3-1/4 7.00 22.09 3-1/2″-4 15.90 8.60 7.75 1.09 9.28 3300 240 lb
